EPD13.3 PoE transformer

2020-09-15



EPD13.3 PoE transformer

Form factor EPD-13.3 is a low profile to reduce EMI. The advantage of EPD-13.3 is capable with EP-13. Height of EPD-13.3 is maximum 10mm which is lower than height of EP-13. At the same time, it can replace EFD-15 and reduce the use of PCB.
Size of EPD-13.3 is 16.0mm*13.5mm*10.0mm maximum. The application of form factor EPD-13.3 could be used on PoE (Power over Ethernet) DC/DC flyback and forward isolated products with working voltage 250KHz and input voltage from 36V to 72V return. The chi-type output is 3.3V/3.6A, 5V/2.4A and 12V/1A etc. The forward-type output is 3.3V/6A, 5V/5A, 12V/2.1A and so on...
Customization is available.
